Three ways to build an effect

Start at the top. Each step down takes a little more code and gives you more control. Stop at whichever level does what you need, and mix levels freely in one effect.

1. 1Effect builderNo code to write

   Pick tracks, drag sliders while the curves update, and copy the finished Luau into your game.

2. 2Ready-made tracksA line of code per move

   Shake, Kick, Edge, Flash and more, each with a few options. Because it's code, values can come from your game: a shake that grows with damage, a tint picked per status effect.

3. 3Primitives & driversFull control

   Drive any of the eight primitives with any curve: follow live data like health or speed, chain and loop shapes, move the camera's position, layer coloured rings in the vignette, and react to where a hit came from.

Installation

MotionFX comes as a single model that lands in Workspace, with two scripts inside:

1. Get MotionFX on the Creator Store, then insert it into your place from the Toolbox (Inventory → My Models).
2. To try the demo, press Play. The example script runs straight from the model, and the keys are listed on the Examples page.
3. Move the MotionFX ModuleScript into ReplicatedStorage, then delete the rest of the model. The example stops working once the module isn't next to it.
4. Require MotionFX from your own client scripts, as in the Quick start below.

Quick start

Play a built-in preset by its enum entry or by its plain string name. Both resolve through the same lookup:

local ReplicatedStorage = game:GetService("ReplicatedStorage")

local MotionFX = require(ReplicatedStorage.MotionFX)
local FX, Drive = MotionFX.Enum, MotionFX.Drive

MotionFX:Play(FX.Impact.Explosion)   -- or MotionFX:Play("Explosion")

-- Options: scale it down and push the camera backwards
MotionFX:Play(FX.Impact.Explosion, {
	Intensity = 0.6,
	Params = { Direction = Vector3.new(0, 0, 1) },
})

Define your own effect from ready-made tracks. No drivers needed, and the Effect builder writes this for you:

local Track = MotionFX.Track

MotionFX:Create("Hit", {
	Tracks = {
		Track.Kick({ Pitch = 4 }),
		Track.Shake({ Strength = 1, Release = 0.6 }),
		Track.Edge({ Color = Color3.fromRGB(150, 0, 0) }),
		Track.Sound(MotionFX.Sounds.Shake),
	},
})

MotionFX:Play("Hit")

For full control, build each track from one primitive and one driver (Your first effect walks through it step by step):

MotionFX:Create("Heartbeat", {
	Retrigger = "Refresh",
	Tracks = {
		{ Primitive = "Sound", SoundId = MotionFX.Sounds.Heartbeat, Volume = 0.8, FadeOut = 0.3 },
		{
			Primitive = "FOV",
			Driver = Drive.Sequence(
				Drive.Spring({ Kick = -2.5, Frequency = 5, Damping = 0.5 }),
				Drive.Spring({ Kick = -1.5, Frequency = 5, Damping = 0.5 })
			),
		},
	},
})

local handle = MotionFX:Play("Heartbeat")
handle.Finished:Wait()

Or skip naming an effect and drive a primitive directly:

-- Desaturate the screen until stopped
local grade = MotionFX:Apply("Color", Drive.Constant({ Saturation = -0.6 }), { FadeIn = 0.3 })
task.wait(2)
grade:Stop(0.5)

What's inside

The MotionFX ModuleScript is the whole API. These are the modules inside it:
